LA Rams Stadium

Copper Coated Flange LA Rams Stadium1
Copper Coated Flange LA Rams Stadium2
Copper Coated Flange LA Rams Stadium3
Copper Coated Flange LA Rams Stadium4
Copper Coated Flange LA Rams Stadium5
Copper Coated Flange LA Rams Stadium7
Copper Coated Flange LA Rams Stadium6
Hollywood Park, Los Angeles California

SoFi Stadium in Los Angeles, California is the new home of the Los Angeles Rams and the Los Angeles Chargers NFL teams, opened in summer 2020 at a cost of approx. $2.6 billion dollars.

It is an indoor / outdoor stadium and precinct featuring a fixed, translucent roof covering both the stadium proper and an adjacent pedestrian plaza. The stadium bowl itself has open sides and seats up to 70,000 spectators for most events with the ability to expand up to 1000,000 capacity for larger events. The stadium design features “the Oculus”— an ovular, double-sided 4K HDR video board that suspends from the roof over the field. The structure weighs approximately 2.2 million pounds (1,000 t) and also houses the stadium’s 260-speaker audio system.

CTS Flange supplied industrial plumbing Flanges for the project including our Copper Coated flange which was used extensively throughout the HVAC-R systems of the stadium and surrounding buildings, including a 200,000 square feet (19,000m2) facility neighbouring the stadium which includes a live TV studio and an outdoor broadcast studio.

CTS Copper Coated Flange 150lb

Download Brochure
CTS Copper Coated Flange 150lb Brochure
Submittal / Data Sheet
CTS Copper Coated Flange 150lb Spec Data Sheet

Specifications

SERVICE TEMPERATURE: -66F to +400F

DIMENSIONS OF SOLDER JOINT Manufactured to ASME 16.22

Size Code Working Pressure
(at atmospheric)
Material Thickness
1-1/2″ CC015 450 PSI Plate Steel .63
2″ CC002 450 PSI Plate Steel .63
2-1/2″ CC025 450 PSI Plate Steel .63
3″ CC003 450 PSI Plate Steel .63
4″ CC004 450 PSI Plate Steel .709
5″ CC005 450 PSI Plate Steel .748
6″ CC006 450 PSI Plate Steel .866

Size Length
(K) Min
Female End
(F)
Depth (G)
Min
Thickness (T)
Min
ID (O)
Min
OD Cu Flange
(L) Min
    Min Max
1-1/2″ 1.60 1.62 1.63 1.09 .051 1.47 3.10
2″ 1.85 2.12 2.33 1.34 .059 1.94 3.70
2-1/2″ 2.02 2.62 2.63 1.47 .067 2.42 4.20
3″ 2.35 3.12 3.13 1.66 .075 2.89 5.00
4″ 2.81 4.12 4.13 2.16 .096 3.84 6.20
5″ 3.87 5.12 5.13 2.66 .111 4.70 7.30
6″ 4.31 6.12 6.13 3.09 .124 5.72 8.40

Features

  • No EPDM insulator required
  • Copper on copper eliminates the risk of electrolysis occurring between insert and flange
  • Sizes 1-1/2″ thru 6″
  • 100% lead free
  • CC series copper flanges available in 150lb
  • Flanges drilled to ANSI B 16.5
  • Ideal for harsh environments, either in ground or exposed to aggressive atmospheric conditions
  • Suitable for water, gas, steam and other high pressure applications both above and below ground
  • Copper component manufactured to ASME 16.22
  • Backing flange manufactured to ASTM B16.5
Copper Coated Cta

Indiana, Kentucky, Ohio, Western Pennsylvania and West Virginia

CTS USA Agent for: Disney McLane (Indiana, Kentucky, Ohio, Western Pennsylvania and West Virginia)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Disney McLane

Ohio

Address
47737 Reinhold Drive
Cincinnati, Ohio 45237

Contact
Telephone: 800-542-1682
Telephone: 877-476-1682
E-mail: orders@disney-mclane.com
Website: www.disney-mclane.com

Central and Northern New Mexico

CTS USA Agent for: Central and Northern New Mexico

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Jack Toland

El Paso, TX

Address
4600 Grape St.
Denver, CO 80216

Contact
Telephone: (505) 205-6585
E-mail: JToland@RKRnet.com
Website: www.rkrnet.com

Southern New Mexico & El Paso, Texas

CTS USA Agent for: Southern New Mexico & El Paso, Texas

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Albert Calderon

El Paso, TX

Address
4600 Grape St.
Denver, CO 80216

Contact
Telephone: (915) 491-4508
E-mail: albertcal@sbcglobal.net
Website: www.rkrnet.com

Washington, Alaska

CTS USA Agent for: Washington, Alaska

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Baxter-Rutherford

Seattle, WA

Address
920 South Doris
Seattle WA 98108

Contact
Telephone: 206 762 4888
Fax: 206 767 4386
Website: www.baxter-rutherford.com

Utah & Southern Idaho

CTS USA Agent for: Utah & Southern Idaho

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

R. E. Fitzpatrick Sales, Inc.

West Jordan, UT

Address
4109 West Nike Drive
West Jordan UT 84088

Contact
Telephone: 801 282 0700
Fax: 801 282 0600
Email: sales@fitzpatricksales.com
Website: http://www.fitzpatricksales.com

Texas (Southeast – Houston)

CTS USA Agent for: Texas (Southeast – Houston)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Stephen & Stephenson Inc

Houston, TX

Address
4626 Windfern Rd
Houston TX 77041

Contact
Telephone: 713-227-7254
Fax: 713-227-4946
Email: sales@stephenstephenson.com
Website: www.stephenstephenson.com

Texas (South)

CTS USA Agent for: Texas (South)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Dillard Associates

San Antonio, TX

Address
6100 Tri County Parkway Schertz
San Antonio TX 78154

Contact
Telephone: 210-824-4881
Fax: 210-826-7839
Email: jmccarter@dillardassoc.com
Website: http://www.dillardassoc.com

Texas (Northern)

CTS USA Agent for: Texas (Northern)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Dillard Associates

North Texas

Address
1504 Selene Drive
Carrollton, TX 75006

Contact
Telephone: 972-278-2000
Fax: 972-271-0970
Email: bboyd@dillardassoc.com
Website: http://www.dillardassoc.com

Tennessee (Nashville)

CTS USA Agent for: Tennessee (Nashville)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Southern Marketing Group

Nashville, Tennessee

Address
4068 Hatcher Circle
Memphis, TN 38118

Contact
Name: Jeff Hilton or Andy Owens
Telephone: 901-547-0042
Fax: 901-547-0032
Email: jefferysmg@gmail.com
Website: www.southernmarketinggroup.com

Tennessee

CTS USA Agent for: Tennessee

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Southern Marketing Group

Memphis, TN

Address
4068 Hatcher Circle
Memphis, TN 38118

Contact
Name: Jeff Hilton or Andy Owens
Telephone: 901-547-0042
Fax: 901-547-0032
Email: jefferysmg@gmail.com
Website: www.southernmarketinggroup.com

Rocky Mountains

CTS USA Agent for: Rocky Mountains

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

RKR

Denver, CO

Address
4600 Grape Street
Denver, CO. 80216

Contact
Telephone: (303) 321-7610
Fax: (303) 399-9420
Website: http://rkrnet.com

Oregon, Western Idaho

CTS USA Agent for: Oregon, Western Idaho

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Baxter-Rutherford

Vancouver, WA

Address
7509 North East 47th Ave, Unit C
Vancouver WA 98661

Contact
Telephone: 503 227 7203
Website: http://www.baxter-rutherford.com

Oklahoma

CTS USA Agent for: Oklahoma

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Dillard sales, DBA

Tulsa, Ok

Address
Cornerstone Sales
11437 E. 20th St.
Tulsa, Ok. 74128

Contact
Telephone: 918-280-1200
Contact person: Micah Mosely
E-mail: micah@cornerstonesales.net
Website: www.cornerstonesales.net

North & South Carolina

CTS USA Agent for: North & South Carolina
Quality Marketing Logo

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Quality Marketing

Charlotte, NC

Address
1327 Wood Branch Drive,
Charlotte, NC 28273

Contact
Telephone: 704-599-9407
E-mail: jayh@qmarketing.biz
Website: qmarketing.biz

New Jersey (Southern), Pennsylvania (Eastern)

CTS USA Agent for: New Jersey (Southern), Pennsylvania (Eastern)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

N.H. Yates Co.

Pottstown, PA

Address
56 Lightcap Road
Pottstown PA 19464

Contact
Telephone: 610-495-5600
Fax: 610-495-3072
E-mail: Renae.dowdy@nhyates.com
Website: www.nhyates.com

New Jersey (Northern), New York

CTS USA Agent for: New Jersey (Northern), New York

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Conroy & Griese Sales Inc.

Cherry Hill, NJ

Address
1951 Old Cuthbert Road – Suite 307
Cherry Hill NJ 08034

Contact
Telephone: (856)-429-2660
Fax: (856)-429-2230
E-mail: griesek@aol.com

New England (MA, CT, NH, VT, ME, Upstate New York)

CTS USA Agent for: New England (MA, CT, NH, VT, ME, Upstate New York)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Perrotti Sales

Oxford, MA

Address
P.O. Box 248
Oxford MA 01540

Contact
Telephone: (508) 943-0528
Fax: (508) 943-6382
E-mail: rperrotti@perrottisales.com
Website: http://www.perrottisales.com

Nebraska – Omaha

CTS USA Agent for: Nebraska – Omaha

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Service Reps Inc.

Omaha, NE

Address
15030 A Circle
Omaha NE 68144

Contact
Telephone: 402-333-2095
Fax: 402-333-2610
Website: http://www.servicerepsinc.com

Mississippi

CTS USA Agent for: Mississippi

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Southern Marketing Group

Richland, MS

Address
4068 Hatcher Circle
Memphis, TN 38118

Contact
Name: Jeff Hilton or Andy Owens
Telephone: 901-547-0042
Fax: 901-547-0032
Email: jefferysmg@gmail.com
Website: www.southernmarketinggroup.com

Minnesota, Wisconsin, North Dakota, South Dakota

CTS USA Agent for: Minnesota, Wisconsin

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Minnesota

Michel Sales

Address
521 Phalen Blvd,
St Paul, MN 55130

Contact
Phone: (651) 287-2640

Sales Contact
Name: Rick Michel
Phone: (651) 287-2643
Website: michelsales.com


Wisconsin

Michel Sales

Address
11360 W. TheoTrecker Way
West Allis, WI 53214

Contact
Phone: (414) 207-8982

Sales Contact
Name: Rick Michel
Phone: (651) 287-2643
Website: michelsales.com

Michigan

CTS USA Agent for: Michigan

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Sales Service Plus, Inc.

Plymouth, MI

Address
45606 Mast Street
Plymouth MI 48170

Contact
Telephone: 734 454 7620
Fax: 734 454 7632
Website: http://www.salesserviceplus.com

Maryland, Delaware, Virginia, Washington DC

CTS USA Agent for: Maryland, Delaware, Virginia, Washington DC

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

N.H. Yates Co.

Cockeysville, MD

Address
117c Church Lane
Cockeysville MD 21030-3401

Contact
Telephone: 410 667 6300
Fax: 410 667 9201
Email: matt.cornelius@nhyates.com
Website: http://www.nhyates.com

Louisianna

CTS USA Agent for: Louisianna

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Grant and Assoc.

Elwood, LA

Address
601 South Al Davis Road
Elwood LA 70123

Contact
Telephone: 504-733-2999
Fax: 504-733-9485
Website: http://www.grant-assoc.com

Sales Contact
Name: Walt Kenning

Kansas

CTS USA Agent for: Kansas

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

McCoy Sales

Kansas City, KS

Address
PO Box 5249
750 Cheyenne Ave
Kansas City KS 66105

Contact
Telephone: 913 342 4904
Fax: 913 321 5720
Website: http://mccoysaleskc.com

Iowa (Eastern)

CTS USA Agent for: Iowa (Eastern)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Service Reps Inc.

Cedar Rapids, IA

Address
3617 Eagle Dr SW
Cedar Rapids IA 52404

Contact
Telephone: 319 855-8687
Website: http://www.servicerepsinc.com

Iowa (Central)

CTS USA Agent for: Iowa (Central)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Service Reps Inc.

Ankeny, IA

Address
401 NE Innsbruck Dr
Ankeny IA 50021

Contact
Telephone: 515 344-8264
Website: http://www.servicerepsinc.com

Illinois & NW Indiana

CTS USA Agent for: Illinois & NW Indiana

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Coming soon

In the mean time, please call CTS Fabrication at +1 916 852 6303.

Hawaii

CTS USA Agent for: Georgia

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Delco Sales, Inc.

Waipahu, HI

Address
94-1388 Moaniani Street, Unit 114
Waipahu, HI 96797

Contact
Telephone: 808 842 7900
Fax: 808 842 9625
E-Mail: sales@delcosales.com
Website: http://www.delcosales.com

Georgia

CTS USA Agent for: Georgia

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Spotswood, Cotton and Welsh Inc.

Norcross, GA

Address
6235 Atlantic Blvd.
Norcross GA 30071

Contact
Telephone: 1-800-255-7768 (toll free), 770-447-1227
Fax: 770-263-6899
E-Mail: Jim.kendall@SCWsales.com
Website: http://www.scwsales.com

Florida

CTS USA Agent for: Florida

Yates LLC

Contact
Yates LLC – Nick Nodae
Telephone: 904-522-3269
E-Mail: njnodae@nhyates.com

Yates LLC – Cristobal (Toby) Diaz
Telephone: 954-579-3454
E-Mail: tdiaz@nhyates.com

California (Southern)

CTS USA Agent for: California (Southern)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Delco Sales inc.

Anaheim, CA

Address
5375 E Hunter Ave,
Anaheim, CA 92807

Contact
Telephone: 714 888-2444
Fax: 714 888-2448
E-Mail: sales@delcosales.com
Website: http://www.delcosales.com

California (Northern)

CTS USA Agent for: California (Northern)

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

CTS USA Head Office

Rancho Cardova, CA

Address
11220 Pyrites Way, Suite 300
Rancho Cordova CA 95670

Contact
Telephone: +1 916 852 6303
Fax: +1 916 852 6308
E-Mail: info@ctsflange.com
Website: http://ctsflange.com

Sales Contact
Name: John Franzman
Cell: 916-834-7633
Email: john@ctsflange.com

Arkansas

CTS USA Agent for: Arkansas

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Southern Marketing Group

Memphis, TN

Address
4068 Hatcher Circle
Memphis, TN 38118

Contact
Name: Jeff Hilton or Andy Owens
Telephone: 901-547-0042
Fax: 901-547-0032
Email: jefferysmg@gmail.com
Website: www.southernmarketinggroup.com

Arizona, Nevada

CTS USA Agent for: Arizona, Nevada

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Southwestern Industrial Sales

Chandler, AZ

Address
130 E. Comstock Drive
Chandler AZ 85225

Contact
Telephone: 480-458-5838
Fax: 480-458-5843
E-Mail: sales@sw-ind.com
Website: http://sw-ind.com

Alabama & Florida Panhandle

CTS USA Agent for: Alabama & Florida Panhandle

How to get there

Click button “Get Directions” on the right corner of the below map, fill in your address into the address field and the shortest route will be calculated.

Williams & Associates

Birmingham, AL

Address
2661 Queenstown Road
Birmingham AL 35210

Contact
Telephone: 205 833-6666
Fax: 205 833-8434
E-Mail: willassoc@bellsouth.net
Website: http://www.wareps.com

Graton Resort & Casino

288 GOLF COURSE DR W, ROHNERT PARK, CA 94928

Graton Resort & Casino is an Indian casino outside Rohnert Park, California, that opened on November 5, 2013. It is owned by the Federated Indians of Graton Rancheria and operated by Station Casinos. The casino has 3,000 slot machines, 144 table games, and a poker room. A 200-room hotel is planned for a later phase of construction.

Utah Data Center

N 11600 W, SARATOGA SPRINGS, UT 84045

The Utah Data Center, also known as the Intelligence Community Comprehensive National Cybersecurity Initiative Data Center. Its purpose is to support the Comprehensive National Cybersecurity Initiative.

Advocate Good Samaritan Hospital

3815 HIGHLAND AVE, DOWNERS GROVE, IL 60515

Advocate Good Samaritan Hospital is a 333-bed community hospital located in Downers Grove, in the US state Illinois. The hospital opened in 1976, and operates the only Level I trauma center in the county of DuPage.

Joint Force Headquarters National Capital Region

1504 MADISON AVE, FORT EUSTIS, VA 23604

Joint Force Headquarters National Capital Region (JFHQ-NCR) is directly responsible for the homeland security and defense of the Washington D.C. area as well as surrounding counties in Virginia and Maryland. Primarily made up of joint military units within the National Capital Region and led by the United States Army via the Military District of Washington (MDW), the JFHQ-NCR assists federal and local civilian agencies and disaster response teams in the event that the capital area’s security is or possibly could be breached by acts of terrorism.

St. Jude Children’s Research Hospital

262 DANNY THOMAS PLACE, MEMPHIS, TENNESSEE, UNITED STATES

St. Jude Children’s Research Hospital, founded in 1962, is a pediatric treatment and research facility focused on children’s catastrophic diseases. It is located in Memphis, Tennessee, and is a nonprofit medical corporation.

World Trade Center Memorial

180 GREENWICH ST, NEW YORK, NY 10007

9/11 Memorial Plaza is a tribute to the past and a place of hope for the future — the 9/11 Memorial Plaza is alive with twin spirits of remembrance & renewal. The 8-acre park is a supremely contemplative sanctuary, composed of a grove of nearly 400 white oak trees, and the largest manmade waterfalls in the United States. Set within the footprints of the original Twin Towers, each pool is approximately 1-acre in size. The names of every person who perished in the terror attacks of February 26, 1993 & September 11, 2001 are honored in bronze around the twin Memorial pools.

Federal Reserve

502 S SHARP ST, BALTIMORE, MD 21201

The Federal Reserve Bank of Richmond Baltimore Branch Office is one of the two Federal Reserve Bank of Richmond branch offices. The Federal Reserve Bank of Richmond’s Baltimore Branch is an operational and regional center for Maryland, the metropolitan Washington D.C. area, Northern Virginia, and northeastern West Virginia. The Baltimore branch is part of the Fifth District and has the code E5.

It supports Check 21 operations, supplies coin and currency to financial institutions and works to maintain stability in the financial sector throughout the Fifth District and also works with local elected officials and non-profit organizations to support fair housing initiatives throughout the Fifth District.

Globe Life Park in Arlington

1000 BALLPARK WAY, ARLINGTON, TX 76011

Globe Life Park in Arlington is a stadium in Arlington, Texas, located between Dallas and Fort Worth. It is home to the American League’s Texas Rangers, and the Texas Rangers Baseball Hall of Fame. This baseball stadium with a granite & brick facade seats 48,000+ fans.

Levi’s Stadium

4900 MARIE P DEBARTOLO WAY, SANTA CLARA, CA 95054

Levi’s Stadium is a football stadium located in Santa Clara, California, in the San Francisco Bay Area. It currently serves as the home of the San Francisco 49ers of the National Football League since 2014.Levi’s® Stadium was designed by HNTB and built by Turner/Devcon for the Santa Clara Stadium Authority. The structure takes advantage of the Silicon Valley climate and is predominantly open and airy, while also environmentally friendly.

eBay

4010 N 3RD ST, PHOENIX, AZ 85012

eBay Inc. (stylized as “ebay” since late 2012) is an American multinational corporation and e-commerce company, providing consumer-to-consumer and business-to-consumer sales services via the internet. EBay’s Newest Data Center is in a Very Hot Place. Phoenix Arizona. The facility is capable of free cooling year round in Phoenix despite the city’s notorious heat. The facility has an oversized cooling tower that runs a condenser water loop system underneath the floor.

Golden 1 Center

547 L ST, SACRAMENTO, CA 95814

Golden 1 Center is a multi-purpose indoor arena, currently under construction in downtown Sacramento, California. It sits partially on the site of the former Downtown Plaza shopping center.[5] The publicly owned arena is part of a business and entertainment district called Downtown Commons, otherwise known as DoCo, which will include a $250 million 16-story mixed-use tower.

The arena will host concerts, conventions and other sporting and entertainment events.

SLS Las Vegas Hotel & Casino

2535 S LAS VEGAS BLVD, LAS VEGAS, NV 89109

A sleek, seductive retreat awaits at SLS Las Vegas is an all-encompassing, mixed-use resort and casino with more than 1,600 guest rooms and suites, 30,000 square feet of meeting space, and a collection of sbe’s acclaimed restaurant and nightlife brands.

Assembly of God Church

DENTON, TEXAS

A large complex requiring a total of 45 flange installations. The contractor and installers advised the ease of installation of CTS Flanges saved approximately 20-30 minutes per valve installation saving approx between 10 and 15 hours over the total job. This cost saving both increased profitability and proved a better quality, longer lasting installation to the customer.

© CTS Flange USA. All rights reserved
